New Arrival Large Digital E-Ink 13.3 Inch Black And White E Ink Screen E Ink Monitor Low-Power Large Size, Bus Stop Board
-
10-199 PcsCN¥729.21
-
200-1999 PcsCN¥729.21
-
>=2000 PcsCN¥729.21
- Samples:
- US$ 729.21 /Pcs,Contact us for sample pricing 1 Pcs (Min. Order)
- Customization:
-
Customized logo(Min. Order: 200 Pcs)Customized packaging(Min. Order: 2000 Pcs)Graphic customization(Min. Order: 5000 Pcs)








- Company Overview
- Production Capacity
- Quality Control
- R&D Capacity
- Trade Capacity
- Factory inspection reports
- CE Certified.
- Valid from 2016-12-25 until 2049-12-31
13.3" E Ink Digital Photo Frame – Product Description
Specifications (Sample)
EC 13.3 inch Product specifications | ||
Model Name | S133EC-0 | |
| Display Size(diagonal) | 13.3 inch |
Colour | Black and white | |
Fitting method | 3mm cover glass with AG and UV | |
Front light | Support,max power 1.56W6V 260MA typ.1.32W | |
| Resolution | 1600*1200 |
DPI | 150 | |
Aspect Ratio | 4:3 | |
Display Viewing Area(HV)(mm) | 270.4(H)×202.8(V)mm | |
View Angle(H/V) | 178°(H)/178°(V) | |
| HDMI-OUT | 1x |
RJ45 | 1 self-adaptive 10M/100M | |
USB2.0 | 2x USB 1x,USB/OTG 1x | |
TF cad | 1x Reserved(extend maximum 128G)(Optional) | |
4G | 1x Optonal | |
| System | Android 7.1 |
CPU | Cortex A71.2G Quad-core ARM Cortex A71.2G | |
DDR3 | 1G | |
EMMC | 8G | |
WIFI | 2.4G | |
BT | 4.0 | |
Buttons | POWER,UP,DOWN,RESET | |
| Power supply mode | Power adapter/Solar power supply |
Working Power(updating) | ≤3.5W | |
Standby power(non-updating) | ≤0.01W | |
Shutdown power | ≤0.001W | |
Adapter power supply | Compatible with 15-20V wide voltage input | |
Solar power | Support | |
| For further development | Provide API and SDK |
Update Time | ≤2s | |
Update Method | Via USB Flash Disk,Android app | |
Language | Multiple language(English by default) | |
| Protection Level | IP65 |
Crashproof Level | IK08 | |
Product Dimension | 375*250*65mm | |
Dimension&Weight | Net Weight | 4.75kg |
| Storage Temperature | -25℃-70℃ |
Working Temperature | -15℃-65℃ | |
Humidity | 20%-90% |
Overview
- Sleek 13.3-inch E Ink display delivers crisp, paper-like visuals with exceptional energy efficiency. Designed to showcase your memories with minimal distraction and maximum elegance.
- Auto-on ambient display keeps your photos, notes, and calendars visible without bright backlight, perfect for living rooms, offices, and bedside setups.
- Low power consumption and fanless operation create a quiet and eco-friendly viewing experience.
Key Features
- High-Contrast E Ink Panel (13.3" / A4 size equivalent): Vivid grayscale rendering that remains easy on the eyes in any lighting condition.
- Auto-rotate & Slideshow Modes: Seamless transitions between photos, with configurable duration and transition effects.
- Wi-Fi & Cloud Sync: Drop photos from your phone or computer via cloud albums, or share a link to family members for collaborative albums.
- Dual-Source Media: Supports USB drive, microSD card, and networked shares for flexible photo sourcing.
- Calendar, Clock & Notes: Built-in widgets to keep you organized without extra devices.
- Ambient Light Sensor: Automatically adjusts display brightness to maintain readability while conserving power.
- Suttle Frame Bezel & Wall-Mountable: Modern, unobtrusive design with optional wall-mount kit for versatile placement.
- Privacy & Security: Local photo storage with optional password protection and device encryption.
Design & Display
- Display: 13.3" E Ink display with high-contrast grayscale and wide viewing angles.
- Resolution: Optimized for photo viewing with sharp image fidelity and typography.
- Form Factor: Ultra-thin profile, lightweight chassis, and a minimalist bezel to complement any decor.
- Mounting: Desktop stand included; optional wall-mount kit available.
Performance & Connectivity
- Processor & Memory: Efficient chip for smooth slideshow playback and real-time widgets.
- Storage: Local storage for cached photos; expandable via USB/microSD as needed.
- Networking: Wi-Fi connectivity (2.4 GHz) for cloud syncing and app control.
- App Control: Companion app for iOS/Android to curate albums, schedule slideshows, and manage widgets.
Media & File Support
- Photos: JPEG, PNG, BMP formats; support for common photo sizes.
- Videos: Primarily optimized for static photo display; video playback may be limited or unsupported to preserve power efficiency (confirm exact support in final spec).
- Other: supports text notes and calendar data to enrich the display.
Use Scenarios
- Family Moments: Share and display rotating photos from family albums across devices.
- Home Office / Desk: Calendar, clock, and notes widgets beside a rotating photo gallery.
- Living Room Decor: Quiet, paper-like display that blends with art and decor.
- Gifts & Memorabilia: A thoughtful way to present memories in a stylish, low-power frame.
Packaging & Accessories
- 13.3" E Ink Digital Photo Frame
- Desk stand
- USB-C / power adapter
- Quick start guide
- Optional wall mount kit (sold separately)
In the Box
- 1 x 13.3" E Ink Photo Frame
- 1 x Stand
- 1 x Power Adapter
- 1 x Quick Start Guide
Why Choose This Frame
- Low Power, High Clarity: E Ink technology offers long-lasting display with minimal energy use.
- Elegant Minimalism: A modern, distraction-free way to showcase memories.
- Smart Sharing: Easily collect and display photos from family members and devices.
FAQ (Common Questions)
- Q: Can I play videos on this frame?
A: The frame is optimized for static photos and text displays to maximize power efficiency and readability. (If video support exists, specify formats and limitations.) - Q: How do I transfer photos?
A: Use the companion app, cloud albums, or connect a USB/microSD to load photos directly. - Q: Is there a brightness control?
A: Yes, the frame auto-adjusts brightness via an ambient light sensor, with manual override available in settings. - Q: Can I mount it on a wall?
A: Yes, wall-mount compatible with the optional kit.
A: The frame is optimized for static photos and text displays to maximize power efficiency and readability. (If video support exists, specify formats and limitations.)
A: Use the companion app, cloud albums, or connect a USB/microSD to load photos directly.
A: Yes, the frame auto-adjusts brightness via an ambient light sensor, with manual override available in settings.
A: Yes, wall-mount compatible with the optional kit.
Customer Support & Warranty
- 1-year limited warranty
- Free software updates for features and security
Call to Action
- Elevate your memories with the 13.3" E Ink Digital Photo Frame. Order now to bring a calm, paper-like display to your home or office.
